INFINITY SIROLIMUS-ELUTING CORONARY STENT SYSTEM
The INFINITY Sirolimus-Eluting Coronary Stent System is a state-of-the-art device used in interventional cardiology to treat coronary artery disease (CAD). It features a fully biodegradable, biocompatible polymer (PLGA) with a precise sirolimus loading density of 1.2 ± 0.2 µg/mm and a uniform 6 µm coating. The stent is designed for consistent drug release, promoting optimal neointimal coverage and reducing the risk of In-Stent Restenosis (ISR) and late thrombosis. Mounted on a hydrophilic-coated PTCA catheter, the system ensures safe and effective stent deployment.
Technical Specification
Stent Specification
Available stent lengths
10, 13, 15, 18, 20, 24, 28, 32, 36, 40, 44 & 48mm
Available stent diameters
2.25, 2.50, 2.75, 3.00, 3.50 & 4.00mm
Stent Material
L605 Cobalt-Chromium (Co-cr) alloy
Stent Material
Open and closed cell design
Stent Platform
Cobal + C
Stent foreshortening
<2%
Stent Recoil
<4%
Stent struct thickness
63µm
Delivery Systems
Delivery System Type
Monorail rapid exchange
Polymer Type
Biodegradable polymer
Nominal Pressure
8 Bar
Rated Burst Pressure
16 Bar
Guidewire Compatibility
0.014″
Guiding Catheter Compatibility
5F
Product Description
is a high-performance stent designed to treat coronary artery disease (CAD). It features very thin struts (45 μm) that help the artery heal quickly after the procedure, reducing the risk of complications. The stent is built with a special locking mechanism that ensures strong support for the artery while minimizing any chance of the stent moving or collapsing.
The stent's design includes:
- Bulge Strut Width (Hinge): 62.5 μm
- Radial Strut Width: 105 μm
- Connecting Strut Width: 63 μm
Made from a strong and flexible cobalt-chromium alloy (CoCr L605), the INFINITY stent combines the best features of several top stent technologies, such as ABLUMINAS DES, SYNERGY, ULTIMASTER, DESYNE, XIENCE, PROMUS, YUKON PC, RESOLUTE, and BIOMATREX, to provide reliable and effective treatment for blocked arteries.
Guidewire Compatibility
Guiding Catheter Compatibility
0.014″
5F
0.018″
5F, 6F and 7F
0.035″
7F, 8F and 9F
Sheath Compatibility
0.014″
4F
0.018″
4F to 5F
0.035″
5F to 7F
